57 17 32N 014 08.13E
OWNER:
MIL AD: FM/Swedish Armed Forces
Bastroppen
Box 305
SE-331 01 Värnamo
PH: +46 (0)10 - 827 10 00
E-mail: f17@mil.se
AFS: ESMVZTZX
Website: KALLINGE (pdf) (In Swedish)
"Hagshult Airport is located 7 NM/12,9 KM NNE of Värnamo"
Welcome to Värnamo
Värnamo Tourist Center
Photos above
TOP: JAS 39 GRIPEN
MIDDLE: VÄRNAMO CITY
CIV TAF not produced
CIV METAR not produced
ESMV/---
571732N 0140813E RWY centre point
6° E (2020)/+0.2 increasing
556 ft/info not avbl
HAGSHULT TWR
NIL
HAGSHULT TWR Primary (HX) VDF:
136.250 MHz
HAGSHULT PRECISION (HX) - MIL operations only:
125.800 MHz
HAGSHULT APPROACH (HX):
121.150 MHz
132.250 MHz, VDF, By directive from ATS
GND:
NIL
ATIS:
NIL
See TWR above
HAGSHULT APPROACH (HX):
121.150 MHz
132.250 MHz, VDF, By directive from ATS
NIL
5000 ft AMSL-
VFR Entry/Exit point
SKILLINGARYD: 572405N 0140435E
HILLERSTORP: 571747N 0135547E
SE VÄRNAMO: 570926N 0140508E
RUSKEN: 571836N 0142120E
Reporting point
AMYNNINGEN 582640N 0153721E
Holding
FRYELE: 571500N 0140957E
TVÄRBÄCKEN: 571930N 0140451E
Hours of applicability
CTR is established during hours of TWR, times announced on NOTAM.
Hagshult TMA a
[C] 121.150 MHz
FL 05
_______
2000 AMSL
RESTRICTION AREAS
1. ES R30A
24500 AMSL
------------
GND
2. ES R30B
24500 AMSL
------------
GND
RUNWAYS AND LANDING AIDS
RWY 04
Dimension: Length 2020 m Width 40 m
SURFACE: Asphalt PCN -
THR ELEV: 556 ft
THR COORD: 571709.13N 0140732.94E
DECLARED DISTANCES
TORA: 2050 m
TODA: 2050 m
ASDA: 2050 m
LDA: 2050 m
APPROACH AND RUNWAY LIGHTNING
APCH LGT: -
THR LGT: GREEN
VASIS: PAPI
RWY EDGE: 2050/60 m, White, Caution zone, 600 m yellow, LIL/LIH
RWY 22
Dimension: Length 2020 m Width 40 m
SURFACE: Asphalt PCN -
THR ELEV: 555 ft
THR COORD: 571756.69N 0140855.55E
DECLARED DISTANCES
TORA: 2050 m
TODA: 2050 m
ASDA: 2050 m
LDA: 2050 m
APPROACH AND RUNWAY LIGHTNING
APCH LGT: LIL/LIH, 450 m
THR LGT: GREEN
VASIS: PAPI
RWY EDGE: 2050/60 m, White, Caution zone, 600 m yellow, LIL/LIH
Remarks: RWY 22: MIL LGT. EFAS.
APRON SURFACE AND STRENGTH
Apron 3 CONC/ASPH PCN -
Apron 5 ASPH PCN -
TWY WIDTH, SURFACE AND STRENGTH
-
ATS
Ref AIP SUP/NOTAM
ATS ARO
As ATS
AD Admin
-
AD Operating hours
PPR
Fuel
-
Handing
-
De-Icing
-
Customs
-
Security
-
Remarks Established at times announced on NOTAM.
Hours of applicability
CTR is established during hours of TWR, times announced on NOTAM.
VFR. Max RWY ref code --
PPR:
PPR for all traffic.
Contact Airport manager
PH +46 10 827 10 00 exch.
E-mail: f17-flygplatschefen@mil.se
Office responsible for TAF preparation
Periods of validity, interval of issuance
CIV TAF not produced
LOCAL TRAFFIC REGULATIONS
NIL
ADDITIONAL INFORMATION
NIL
Hours of applicability
CTR is established during hours of TWR, times announced on NOTAM.
NIL
Traffic circuit
Right hand traffic circuit when RWY 29 is in use
Reporting point
AMYNNINGEN 582640N 0153721E
Holding
RYSTAD:
Hold over Rystad church, north of
point 582620N 0154300E
GOLFBANAN:
Hold west of Stångån over the golf
course, south west of point
582111N 0154402E
Entry / exit point
SKILLINGARYD: 572405N 0140435E
HILLERSTORP: 571747N 0135547E
SE VÄRNAMO: 570926N 0140508E
RUSKEN: 571836N 0142120E
Holding
FRYELE: 571500N 0140957E
TVÄRBÄCKEN: 571930N 0140451E
Jet A1
-
100 LL/ 91/96 UL:
-
MIL standard
AD category for fire fighting:
CAT 6 O/R
Rescue equipment
-
Capability for removal of disabled aircraft
-
Communication failure
NIL
According to AIP
Security charges are set and invoiced by governmental Transportstyrelsen (Swedish Transport Agency) directly to airline operator. See www.transportstyrelsen.se (TSFS 2012:113)
Increased charges outside TWR HR of OPS
Swedavia Annual card for Non-commercial aircraft MTOW 5,700 kg:
Apply for an annual card here >>
Hagshult ESMV is not affiliated with the joint system of annual cards.
NIL
NIL
-
Airport office
PH: +46 (0)13 - 28 30 00
Email: exp-hkpflj@mil.se
Värnamo Flying club (Flygklubb)
Värnamo flygklubb
Besöksadress:
Hagshult flygplats Ya
Ordförande (Chairman)
Pär Svensson
PH: +46 (0)76 - 1389800
Email: ordforande@varnamoflygklubb.se
Website: https://www.varnamoflygklubb.se
See HANDLING above
The AIP links below are obtained externally from LFV AB (publisher of AIP).
AIP updates are based on the AIRAC effective date schedule.
But if the link does not work or is not updated, please log in to
aro.lfv.se: for current information:
ES-AD ESMV 1-1 Download it from here >>
ES-AD ESMV 5-1 Area Chart - ICAO HAGSHULT TMA Download it from here >>
ES-AD ESNQ 6-3 STAR - ICAO RNP STAR RWY 21 Download it from here >>
ES-AD ESMV 7-1 ATC Surveillance Minimum Altitude Chart – HAGSHULT Download it from here >>
ES-AD ESMV 9-1 VAC Download it from here >>
