56 17 28N 012 51.18E
Ängelholms flygplats AB
Ängelholm Helsingborg Airport
SE-262 91 Ängelholm
TEL: +46 (0)431 - 48 45 00
FAX: +46 (0)431 - 48 45 10
E-mail: info@aghairport.se
AFS: ESTAZTZX
Website:
www.aghairport.se
"Ängelholm Helsingborg Airport (AGH) is located appx 7,4 kilometres N of the city centre of Ängelholm"
"Welcome to Ängelholm! - In this perfect location close to the sea, forests and hills, enjoying life is easy – every day! The Rönne river floats through the town centre and enters the sea in Skälderviken, adding to the pleasant atmosphere. Six kilometres of sandy beaches, the Kronoskogen forest and the picturesque town centre are other appealing features of Ängelholm."
https://engelholm.com/en/
"Ängelholm Helsingborg Airport (AGH) is located appx 35 kilometres NE of the city centre of Helsingborg"
"Welcome to Helsingborg! The friendliest city in Sweden!
Where it’s the weekend almost all the time. At least if you agree that the weekend means long beautiful days and endless joy. Are you a nature lover? Choose between wild nature or beautiful gardens and parks. A bon vivant? Helsingborg offers many exciting culinary delights. A culture buff? We have theatres, concerts and museums. Do you love Denmark? It’s just a 20-minute ferry ride to Helsingør. A shopaholic? Check out the list of all our shops."
https://visithelsingborg.com/en/
"Ängelholm Helsingborg Airport (AGH) is located appx 35 kilometres SE of the city centre of Båstad"
"Welcome to Båstad - Bjäre peninsula!
Bastad and Bjärehalvön offers more than 170 qualitative event days. Occasionally, culture, sports and other events spread over the year as a lush lawn. Here you can keep track of what happens during the tennis weeks, when it is time for the Chamber, when the autumn peak; Bastad Hiking Festival takes place, and much more."
https://bastad.com/
ESTA/AGH
561728N 0125118E RWY 14/32 centre point
5° E 2025/+0.2 increasing
62 ft/19 m
ÄNGELHOLM TWR
Phone:
+46 (0)431 - 48 45 50
+46 (0)431 - 202 14
Email address:
ats.angelholm@acr-sweden.se
CO ATS
Peter Kallin
CO ATS Ängelholm & CO ATS Ljungbyhed
+46 (0)708 - 14 54 80
Email address:
peter.kallin@acr-sweden.se
Postal address:
AVIATION CAPACITY RESOURCES AB, ACR
Flygtrafikledningen
Valhall Park
SE-262 74 Ängelholm
ESTAZTZX
ÄNGELHOLM TWR Primary (HO):
127.105 MHz
ÄNGELHOLM TWR Emergency (HO):
121.500 MHz
ÄNGELHOLM APPROACH
132.455 MHz
CTR established during hours of TWR.
GND:
NIL
ATIS:
NIL
132.455 MHz APP ÄNGELHOLM APPROACH
ILS/DME RWY 14 DB
111.30 MHz
NDB:
370.50 (KHz) LB (RWY 14)
414 (KHz) AH (RWY 32)
See AIP for more information
5000 ft AMSL
VFR Entry/Exit point
- TOREKOV 562539N 0123651E
- KARUP 562521N 0125719E
- VASTERSJON 561845N 0130441E
- VARALOV 561128N 0125133E
- FARHULT 561357N 0124428E
Reporting point
- NIL
VFR flight within CTR
a) Altitude in traffic circuit normally 1000 ft except E
RWY period SEP–APR when 700 ft applies.
b) Initial turn after take-off should be avoided below
700 ft, both RWYs.
- CTR established during hours of TWR.
- Johannisberg ATZ with airspace class G penetrates CTR
- The lower limit
of Västerås CTR in this part is 1000 ft AMSL.
- For details see ENR 2.2 and
AD 2 ESOW 6-1.
Obstacle 0.3 NM prior THR penetrates visual segment surface.
RUNWAYS, LANDING AIDS, AD reference code
RWY 14
Dimension: Length 1 945 m Width 45 m
SURFACE: Asphalt PCN 51 F/C/X/U
THR ELEV: 60.2 ft
THR COORD: 561752.12N 0125039.16E
DECLARED DISTANCES
TORA: 1945 m
TODA: 1945 m
ASDA: 1945 m
LDA: 1945 m
LANDING AIDS:
APPROACH AND RUNWAY LIGHTNING
APCH LGT: Barrette CL CAT I 900 m
VASIS: PAPI
LED lights: NIL
RWY 32
Dimension: Length 1 945 m Width 45 m
SURFACE: Asphalt PCN 51 F/C/X/U
THR ELEV: 50 ft
THR COORD: 561706.60N
0125157.16E
DECLARED DISTANCES
TORA: 1945 m
TODA: 2150 m
ASDA: 1945 m
LDA: 1945 m
LANDING AIDS:
APPROACH AND RUNWAY LIGHTNING
APCH LGT: SALS 420 m
VASIS: PAPI
LED lights: NIL
AD reference code (See also - "Types of traffic permitted
(IFR/VFR)", above)
RWY 14/32 code 4C
APRON SURFACE AND STRENGTH
Apron D ASPH PCN 25 F/C/X/T
Apron E ASPH PCN 51 F/C/X/U
Apron W ASPH PCN 51 F/C/X/U
TWY WIDTH, SURFACE AND STRENGTH
TWY A 18 m ASPH PCN 51 F/C/X/U
TWY C 18 m ASPH PCN 51 F/C/X/U
TWY F 18 m ASPH PCN 51 F/C/X/U
TWY G 15 m ASPH PCN 25 F/C/X/T
TWY M 10 m CONC PCN 25 R/C/X/T
TWY F Distance to beginning of RWY 32 is 100 m
Ängelholm/Helsingborg AD may be used only:
MON: Ref AIP SUP/NOTAM
TUE. Ref AIP SUP/NOTAM
WED: Ref AIP SUP/NOTAM
THU: Ref AIP SUP/NOTAM
FRI: Ref AIP SUP/NOTAM
SAT: Ref AIP SUP/NOTAM
SUN: Ref AIP SUP/NOTAM
ATS
Ref AIP SUP/NOTAM
ATS ARO
Ref AIP SUP/NOTAM
AD operator
MON-FRI: 0700-1500 (0600-1400)
AD Operating hours
Ref AIP SUP/NOTAM
Fuel
Ref AIP SUP/NOTAM
Handing
Ref AIP SUP/NOTAM
De-Icing
Ref AIP SUP/NOTAM
Custom
O/R
PH: +46 (0)40 - 661 32 20
IFR/VFR. Max RWY ref code 4C
PPR:
1. PPR outside TWR hours.
Request shall be made during AD operator hours.
Email: ok@aghairport.se
2. PPR for IFR school and training flights at all times.
For request during
TWR hours call ATC
+46 (0)431 - 202 14
3. Daily
Between 2100–0500 (2000–0400) the
aerodrome must not
be used by aircraft certificated in
accordance with
ICAO Annex 16, Volume I, Part II,
Chapter 2.
4. Parking GA
General Aviation Park normally at apron W
LOCAL AERODROME REGULATIONS
1. Daily between 2100–0500 (2000–0400) the
aerodrome must not be used by aircraft certificated in
accordance with ICAO Annex 16, Volume I, Part II,
Chapter 2.
2. Repeated instrument approaches and TGL accepted
after PPR only and during the following hours:
MON–THU 0730–1900 (0630–1800)
FRI 0730–1600 (0630–1500)
SAT, SUN, HOL 0900–1600 (0800–1500)
3. On parking stand APU shall not be operated unless
required for engine start or adjustment of cabin heat. In no
case APU may be started earlier than 15 min before
estimated time for taxiing.
4. IFR traffic shall be ready to start engines when
requesting start-up from ATC.
5. Engines shall be operated at minimum thrust on aprons, due
to jet blast.
6. Transponder code will be communicated during out taxiing.
7. Air traffic outside ATS hours of operation
• Aerodrome consent is required for all air traffic.
• Take-off or landing may only take place when
visibility exceeds 800 m.
• No traffic may take place during twilight and
darkness.
• All traffic within the CTR must transmit their
intention on channel 127.105.
• Ground vehicles can occur without two-way VHF
communication.
Traffic circuit
Right hand traffic circuit outside ATS hours of
operation when RWY 32 is in use.
Outside of TWR HR of OPS
NO INFO
During TWR HR of OPS
NO INFO
Low visibility procedures (LVP) established
• Minimum RVR for departures is 400 m.
• LVP are established and will be in force at latest when RVR
falls below 550 m and/or the cloudbase is less than 200 ft or
on request. The application of LVP will be announced by ATS.
• When LVP is applied only one aircraft or vehicles are allowed in
the LVP area (same as manoeuvring area on ESTA Aerodrome
Chart).
Holding
NORTH:
Hold at Hjärnarp church, north east of
point 561903N 0125338E
SOUTH:
Hold west camping ground, south
west of point 561550N 0124851E
Handling agent(s):
Ängelholms Flygplats AB
1.ÄNGELHOLM HELSINGBORG AIRPORT:
Contact
Operative Coordinator
Phone: +46 (0)431 - 48 45 20
Email: ok@aghairport.se
SITA: NYOOPXH
Handling Request
Airport Charges Pricelist AGH >>
Ängelholms Flygplats AB
SE-262 91 Ängelholm, Sweden
PH: +46 (0)431 - 48 45 00
Email: info@aghairport.se
WWW:
www.aghairport.se
VISITING ADDRESS
Ängelholms Flygplats AB
Margretetorpsvägen 445
262 91 Ängelholm, Sweden
Payments:
Carnet: UVair, Visa/Mastercard, American Express
Custom H24
Immigration 0500-2100 (0400-2000) Other hours O/R
Jet A1 Air BP via Air BP Airport service:
PH: +46(0)431 - 484520
UL91 Air BP via Air BP Airport service:
PH: +46(0)431 - 484520
Major credit cards, including Air BP flightcard and Air BP sterlingcard
Available, Type I and II
AD category for fire fighting:
1. AD category for fire fighting CAT 6.
For commercial traffic exceeding 2500 kg MTOW 180 sec,
other traffic 8 min.
Capability for removal of disabled aircraft Aircraft
Up to CAT C after arrangement, contact:
PH: +46(0)431 - 868 70 53
1. Over the central parts of Ängelholm aircraft should
not be operated below 2000 ft AMSL except when necessary
for take-off or landing.
2. Avoid overflight of the following noise sensitive areas:
- Barkåkra church
- Ängeltofta Gård
- Månstorps Gård
3. The routes for inbound and outbound traffic have
been established also for noise abatement purposes.
Aircraft
shall strictly adhere to assigned route and be operated in
such a manner that unnecessary noise disturbances are not
caused.
If no suitable aerodrome is within reach;
1. SQUAWK 7600
2. Enter CTR via FARHULT – Holding SOUTH
at or below 1500 ft AMSL to traffic circuit.
Transmit blind your intentions.
3. Flash LDG-lights and watch TWR for optical
signals.
According to AIP
1. Security charges are set and invoiced by governmental Transportstyrelsen (Swedish Transport Agency) directly to airline operator. See www.transportstyrelsen.se (TSFS 2012:113) here >>
2. Ängelholm Helsingborg Airport (Ängelholms Flygplats AB) AB - LANDING FEES AND CHARGES
Information about landing fees and conditions of use:
Charges and Conditions of Use from 2022,
Click here >>
(New window with pdf-document)
Increased charges outside TWR HR of OPS
3. Swedavia Annual card for Non-commercial aircraft MTOW 5,700 kg:
Apply for an annual card here >>
Swedavia's annual card system at Ängelholm Helsingborg Airport ESTA applies.
For aircraft with an MTOW less than 5 700 kg, that are not engaged in commercial operation, an annual card can be purchased for an unlimited number of take-offs (includes Take-Off Charge and TNC Charge) from seven Swedavia airports. The card is also valid at all other airports that are affiliated with the joint system of annual cards. For more information, see Swedavia's price list. Please observe that Gävle-Sandviken airport has ceased operations.
4. PRICE REDUCTIONS
A reduction of 50% for training flights arranged by commercial airline operators for
the purpose of acquainting members of staff with new equipment and/or new types
of aircraft and/or training provided that paying passengers or cargo are not carried
For Catering order, at the Airport, please contact:
takeoffcafe@ektv.nu
Via HANDLING (See above)
YES
The airport have a shop immediately after the security check and is open at all departures.
You who travel domestically and within the EU can shop from their range of perfumes, skincare, sweets, souvenirs etc.
Airport Cafeteria “Take Off”
Ängelholm Helsingborg Airport
262 91 Ängelholm, Sweden
PH: +46 (0)431 - 205 1994
Mobile: +46 (0)706 - 091 615
Fax: +46 (0)431 - 205 1995
Carnets Jet A1:
Air BP only
Carnets 91/96 UL:
Prior arrangement required through handling companies.
Oil prior arrangement required.
Via HANDLING (See above)
Credit Cards accepted at the airport:
Major credit cards, including Air BP flightcard and Air BP sterlingcard
Diners Club, Master Card, Eurocard, VISA, UVair and AMEX (American Express)
CEO:
CHRISTIAN ZIESE
Email: christian.ziese@aghairport.se
PH: +46 (0)708 - 68 70 60
Airport Manager (Director):
ULF SVENSSON
Email: ulf.svensson@aghairport.se
PH: +46 (0)708 - 68 70 50
Airlines
SAS/BRA:
Contact the airport information desk
Ängelholms FK (Flying Club)
PH: +46 (0)431 - 44 66 66
www.engelholmsflygklubb.se
Flight Planning room located on apron W.
Follow C – signs
See HANDLING above
The AIP links below are obtained externally from LFV AB (publisher of AIP).
AIP updates are based on the AIRAC effective date schedule.
But if the link does not work or is not updated, please log in to
aro.lfv.se: for current information:
ES-AD ESTA 1-1 Download it from here >>
ES-AD ESTA 2-1 Aerodrome Chart - ICAO Download it from here >>
ES-AD ESTA 5-1 Area Chart - ICAO ÄNGELHOLM TMA Download it from here >>
ES-AD ESTA 6-1 STAR - ICAO RNAV (GNSS) STAR RWY 14 Download it from here >>
ES-AD ESTA 6-3 STAR - ICAO RNAV (GNSS) STAR RWY 32 Download it from here >>
ES-AD ESTA 7-1 ATC Surveillance Minimum Altitude Chart – ÄNGELHOLM Download it from here >>
ES-AD ESTA 8-1 IAC - ICAO ILS z Cat I or LOC z RWY 14 Download it from here >>
ES-AD ESTA 8-2 IAC - ICAO ILS y Cat I or LOC y RWY 14 Download it from here >>
ES-AD ESTA 8-3 IAC - ICAO ILS SA CAT II RWY 14 Download it from here >>
ES-AD ESTA 8-5 IAC - ICAO NDB RWY 14 Download it from here >>
ES-AD ESTA 8-7 IAC - ICAO NDB RWY 32 Download it from here >>
ES-AD ESTA 8-9 IAC - ICAO RNP RWY 14 Download it from here >>
ES-AD ESTA 8-13 IAC - ICAO RNP RWY 32 Download it from here >>
ES-AD ESTA 9-1 VAC Download it from here >>
Taxi Västra Skåne operates bus service to and from the airport with stops in Helsingborg and Ängelholm. Current timetable can be found on Taxi Västra Skåne's website.
PHONE: +46(0)42 - 131313
TAXI VÄSTRA SKÅNE >>
Information on airport homepage >>
NOTE:
The airport currently does not have an airport bus and therefore refers you to a rental car or taxi.
The taxi zone is located right outside the arrivals hall.
You can pre-book a taxi to wait there.
Taxi companies often set a fixed price, but make sure you always ask for the price before starting your journey.
A board with price guidelines can be found in the taxi zone.
(For further info and booking - Click on link):
Information on airport homepage >>
PHONE: +46(0)42 - 38 04 00
BOOKING/CUSTOMER SERVICE (Norway):
+47 (22)-33 42 00
PHONE:+46(0)42-405 26 00
BOOKING/CUSTOMER SERVICE (Norway):
+47 (22)-33 42 00
SFSA Flight Support partners CarTrawler
At Ängelholm Helsingborg Airport, you can rent cars at
Hertz, Avis, Europcar, Mabi, Sixt.
Note: Remember to book your rental car in advance
Globally, CarTrawler offers attractive rates for car hire in over 30,000 locations in more than 145 countries, and with over 1,200 international suppliers.
SFSA Flight Support Car Rental &Transfer services together with CarTrawler search over 1,600 car rental suppliers to find you the lowest price!
We have integrated the service digitally so that you can make your bookings through this website and our mobile airport website from anywhere.
INSTRUCTION (Choose option)
1. Aim your phone camera at the QR code to the left
2. Click on the button up to the right - with the text
"Click here for booking".
Ängelholms flygplats AB
Ängelholm Helsingborg Airport
Margretetorpsvägen 445
SE-262 91 Ängelholm, Sweden
https://www.aghairport.se/
Terminal
Monday Ref AIP SUP/NOTAM
Tuesday Ref AIP SUP/NOTAM
Wednesday Ref AIP SUP/NOTAM
Thursday Ref AIP SUP/NOTAM
Friday Ref AIP SUP/NOTAM
Saturday Ref AIP SUP/NOTAM
Sunday Ref AIP SUP/NOTAM
Air traffic
Monday-Friday Ref AIP SUP/NOTAM
Saturday Ref AIP SUP/NOTAM
Sunday Ref AIP SUP/NOTAM
SFSA Flight Support/Svenskaflygplatser.com does not guarantee the accuracy or timeliness of any information on this site.
Use at your own risk.
NOT to be used as an official source for flight planning, navigation, or use in flight.
NOTE!
Notices, restrictions,and advisories may change at any time and without notice.
Do not attempt any operation whether in the National or in the International Airspace System without first obtaining and understanding a thorough pre-flight briefing.
