65 32 36N 022 07.25E
Swedavia AB
Kiruna Airport
Box 831
SE-981 28 Kiruna, Sweden
PH: +46 (0)10 - 109 46 00
FAX: +46 (0)10 - 109 46 50
Email: krn.groundhandling@swedavia.se
AFS: ESPAZTZX
Website: www.swedavia.se/kiruna
www.swedavia.net/kiruna
"Kiruna Airport (KRN) is located in the municipality of Kiruna only 5,5 kilometres east south east from the city centre"
Visit Kiruna
www.visitkiruna.com
KIRUNA in Swedish Lapland
www.kirunalapland.se
ESNQ/KRN
674917N 0202008E BRG 033.7° GEO 1150 m from THR 03
10° E 2020/+0.2 increasing
1509 ft/460 m
Kiruna TWR
Phone:
+46(0)980 - 680 17
+46(0)980 - 680 20
Email address:
ats.kiruna@lfv.se
Postal address:
LFV
ATS F21
SE-971 73 Luleå, Sweden
AFS: ESNQZTZX
KALLAX TWR Primary (HO):
128.200 MHz
KALLAX TWR Emergency (HO):
121.500 MHz
KALLAX CTL:
125.450 MHz
SWEDEN CTL:
131.055 MHz
PAR KALLAX PRECISION:
119.000 MHz
KALLAX CTL:
125.450 MHz
ILS/DME RWY 21 NQ CAT I
110.30 MHz
NDB:
RWY 21
360 (KHz) OP
VOR:
DVOR DME KIRUNA
115.20 MHz KRA
See AIP for more information
5000 ft AMSL
VFR Entry/Exit point
- VISCARIA 675256N 0200926E
- VOLOS 675935N 0202443E
- KAALAS 674505N 0200207E
- ALTA 674851N 0203537E
- TAIGA 674213N 0202450E
- SISKA 673725N 0201444E
-
VFR Entry/Exit point V.2
- VISCARIA:D 115.20 KRA, D 6, R 305
- VOLOS: D 115.20 KRA, D 10, R 001
- KAALAS: D 115.20 KRA, D 8, R 231
- ALTA: D 115.20 KRA, D 6, R 085
- TAIGA: D 115.20 KRA, D 7, R 158
- SISKA: D 115.20 KRA, D 12, R 182
Reporting point
NIL
Holding
APTAS: Hold north of railway,
north east of
point
674632N 0202612E
NIL
RUNWAYS AND LANDING AIDS
RWY 03
Dimension: Length 2502 m/8209 ft Width 45 m/148 ft
SURFACE: Asphalt PCN 75 F/B/X/T
THR ELEV: 1509 ft,
THR COORD: 674845.54N
0201913.10E
DECLARED DISTANCES
TORA: 2502 m
TODA: 2652 m
ASDA: 2502 m
LDA: 2502 m
APPROACH AND RUNWAY LIGHTNING
APCH LGT: Calvert, CAT I, 900 m
VASIS: PAPI
LED lights: RCL
---------------------------------------
RWY 21
Dimension: Length 2502 m/8209 ft Width 45 m/148 ft
SURFACE: Asphalt: PCN 75 F/B/X/T
THR ELEV: 1432.3 ft,
THR COORD: 674952.75N
0202111.59E
DECLARED DISTANCES
TORA: 2502 m
TODA: 2502 m
ASDA: 2502 m
LDA: 2502 m
APPROACH AND RUNWAY LIGHTNING
APCH LGT: Calvert , CAT I, 900 m
VASIS: PAPI
LED lights: RCL
APRON SURFACE AND STRENGTH
Apron ARENA ASPH ASPH PCN 53/F/B/X/T
Apron ARENA CONC CONC PCN 49/R/B/X/T
Apron TERMINAL ASPH ASPH PCN 45/F/B/X/T
Apron TERMINAL CONC CONC PCN 54/R/B/X/T
Apron HANGAR 2 ASPH PCN 47/F/B/X/T
TWY WIDTH, SURFACE AND STRENGTH
TWY A 23 m ASPH PCN 50 F/B/X/T
TWY B 23 m ASPH PCN 51 F/B/X/T
TWY Y 23 m ASPH PCN 41 F/B/X/T
Kiruna AD may be used only:
MON–FRI: H24
SAT: H24
SUN: H24
Holiday occuring MON–FRI:
H24
ATS
TWR opens 15 min prior AD operating hours.
Closes as AD operating hours.
AD operator
MON-FRI 0800-1600 (0700-1500)
SAT: Closed
SUN: Closed
HOL: Closed
AD Operating hours
MON-FRI: Ref AIP SUP/NOTAM
SAT: Ref AIP SUP/NOTAM
SUN: Ref AIP SUP/NOTAM
Fuel
As AD HR of OPS
Handling
For scheduled flights. Other O/R
Security
Screening and CSRA for scheduled flights,
other O/R
De-Icing
For scheduled flights, other O/R
BY NOTAM
- -
IFR/VFR. Max RWY ref code 4D
NOTE (S)
PPR:
PPR for CIV and MIL ACFT 5 days prior to planned arrival or departure.
The following TFC is exempted: HOSP, STATE, SAR, SKED TFC, SWE/
EU/NATO MIL and operators with sanction agreement.
Requests shall be sent to:
Email: krn.ppr@swedavia.se
PPR required for operations outside AD operational hours (AD CLSD)
subject to a signed agreement.
Applications shall be submitted during
AD operator hours to
Email: krn.safety@swedavia.se
LOCAL AERODROME REGULATIONS
1. Clearance at gate
ATC clearance will be delivered on request prior to start-up.
Such clearance will be issued for RWY in use and
appropriate SID. Transponder code will be communicated
during taxi.
2. Taxi regulations on TWY Y
Maximum wingspan 36 m for taxiing on TWY Y. De-icing of
aircraft with larger wingspan than 36 m shall contact TWR for
special instructions.
3. Taxiing and towing regulations
Vid taxning eller bogsering ska luftfartygets antikollisions- och
positionsljus (om sådana finns) vara påslagna.
When taxiing or towing, the aircraft’s anti-collision and position
lights (if equipped) shall be turned on.
4. Ground movement procedures
Engines shall be operated at minimum power required when
taxiing on Apron Terminal, Hangar 2 and Arena.
Caution advised when turning around on aprons.
Watch out for passengers on aprons.
ADDITIONAL INFORMATION
1. ATS provided from RTC Stockholm.
2. Signalling lamp positioned at R-TWR.
3. Granted exemptions from requirements in CS-ADR-DSN:
• RWY 03/21: first and last quarter of runway has longitudinal
slope of max 1.0%.
• Fixed lighted and not lighted obstacles/terrain penetrate the
following obstacle limitation surfaces according to list:
Approach surface RWY 03
Take-off climb surface RWY 21
Horizontal surface
Conical surface
• RWY 03/21 is not equipped with RCLL.
RVR below 400 m TKOF only to be conducted with LVO approved by the
operator’s competent authority.
Important note(s)
1. Within the Mountainous area of Sweden
See AIP ENR 1.1.14 below
2. When approaching RWY 03, avoid confusion with Kalixfors airfield just south of ESNQ
Aircraft parking
GA - aircrafts at north part of apron 2
Restricted areas
R 51A, R51B and within CTR
Low visibility procedures (LVP) established
LVP will be in force when runway visual range (RVR) falls
below 550 m or when ceiling or vertical visibility is below
200 ft.
The application of LVP will be announced by ATS with the
phrase “low visibility procedures in operation”.
When LVP is applied only one aircraft or only vehicles are
allowed in the manoeuvring area.
When LVP is applied ACFT shall report RWY vacated at
stand on apron.
Kurravaara seaplane base
Extensive helicopter and and seaplane traffic at Kurravaara seaplane base from June to September
No information yet
Handling agent(s):
Swedavia Handling
PH: +46(0)10 - 109 48 00
Fax: +46(0)10 - 109 49 06
Email: lla.handlingrequest@swedavia.se
Web: www.swedavia.se
Fuel supplier
Shell by Shell Self service
Handling
Mikael Öhman
mikael.ohman@swedavia.se
Corporate contact:
Swedavia
Arri Kallonen
Swedavia Handling
arri.kallonen@swedavia.se
PH. +46(0)10 - 109 11 36
Hangar space for visiting ACFT
Available up to B747-400
Jet A1 (and F-35 or AVTUR)
Fuel suppliers:
- Shell Aviation Sweden AB (SHELL)
PH: +46(0)705 - 36 80 32
Fax:
+46 (0)980 - 14904
Email:
nqshell@swedavia.se
For refueling outside the airport opening hours:
Call and order fuel during the airport opening hours
100 LL:
Fuel suppliers (with reference to Shell Aviation website):
- Shell Aviation Sweden AB (SHELL)
PH: +46(0)705 - 36 80 32
Fax:
+46 (0)980 - 14904
Email:
nqshell@swedavia.se
Please note that only JET A1 fuel is available to buy at Kiruna Airport.
Please make sure that you have enough with fuel (Avgas 100 LL or 91/96 UL)
to make it here and then to another location were aviation fuel is available.
If you have any questions regarding 100 LL, please contact Shell Aviation Sweden AB.
Cards Accepted:
Visa Card, Master Card, Others Card, Shell Carnet
Available, Type I and II, mobile unit
AD category for fire fighting:
CAT 6 for SKED TFC other O/R
Aerodrome restrictions
1. IFR making visual approach, VA, should if possible, avoid
flying overhead Kiruna City.
Communication failure
1. Enter CTR via ALTA – Holding APTAS at or
below 2500 ft AMSL to traffic circuit.
Transmit blind your intentions.
2. Flash LDG-lights and watch TWR for optical
signals
According to AIP
Security charges are set and invoiced by governmental Transportstyrelsen (Swedish Transport Agency) directly to airline operator. See www.transportstyrelsen.se (TSFS 2012:113)
Increased charges outside AD Operating hours.
Frequent extension of
operational hours.
Swedavia Annual card for Non-commercial aircraft MTOW 5,700 kg:
Apply for an annual card here >>
Kiruna Airport ESNQ is affiliated with the joint system of annual cards.
Increased charges outside TWR HR of OPS
Spis food and beverages
Opening hours:
Open in conjunction with all departures
Location:
After security
Contact:
Telephone:
+46 (0)980 - 17000
+46 (0)980 - 15800
Catering from SPiS.
The restaurant offers everything from meals for parties and Christmas celebrations to specially composed menus for corporate events. Please contact the restaurant for a price.
NIL
Carnets Jet A1:
Shell
Via HANDLING (See above)
Carnets 100LL
Shell
Credit Card
Via HANDLING (See above)
Credit Cards accepted at the airport:
Diners Club, Master Card, Eurocard, VISA, UVair and AMEX (American Express)
Airport Director
Andreas Fredriksson
Email: andreas.fredriksson@swedavia.se
PH: +46 (0)10 - 109 46 01
Mobile: ?
Airlines
SAS, Norwegian, Amapola, etc.
Contact the airport information desk
Flying Club
Kiruna Flygklubb (FK)
Olle Persson
Click here >>
PH: +46 (0)72 – 733 88 39
Segelflygklubben Kiruna
Click here >>
PH: +46 (0)980 - 152 92
Sjöflygbas Kurravaara
Kiruna Flygklubb (FK)
Click here >>
PH: +46 (0)72 – 733 88 39
See HANDLING above
The AIP links below are obtained externally from LFV AB (publisher of AIP).
AIP updates are based on the AIRAC effective date schedule.
But if the link does not work or is not updated, please log in to
aro.lfv.se: for current information:
ES-AD ESNQ 1-1 Download it from here >>
ES-AD ESNQ 2-1 Aerodrome Chart - ICAO Download it from here >>
ES-AD ESNQ 5-1 Area Chart ICAO KIRUNA TMA Download it from here >>
ES-AD ESNQ 6-3 STAR - ICAO RNP STAR RWY 21 Download it from here >>
ES-AD ESNQ 6-1 STAR - ICAO RNP STAR RWY 03 Download it from here >>
ES-AD ESNQ 6-3 STAR - ICAO RNP STAR RWY 21 Download it from here >>
ES-AD ESNQ 6-5 SID/STAR - ICAO RWY 03 Download it from here >>
ES-AD ESNQ 6-7 SID/STAR - ICAO RWY 21 Download it from here >>
ES-AD ESNQ 7-1 ICAO ATC Surveillance Minimum Altitude Chart – KIRUNA Download it from here >>
ES-AD ESNQ 8-1 IAC - ICAO ILS z or LOC z RWY 21 Download it from here >>
ES-AD ESNQ 8-2 IAC - ICAO ILS y or LOC y RWY 21 Download it from here >>
ES-AD ESNQ 8-3 IAC - ICAO VOR RWY 21 Download it from here >>
ES-AD ESNQ 8-4 IAC - ICAO NDB z RWY 21 Download it from here >>
ES-AD ESNQ 8-5 IAC - ICAO NDB y RWY 21 Download it from here >>
ES-AD ESNQ 8-7 IAC - ICAO VOR z RWY 03 Download it from here >>
ES-AD ESNQ 8-8 IAC - ICAO VOR y RWY 03 Download it from here >>
ES-AD ESNQ 8-9 IAC - ICAO RNP RWY 03 Download it from here >>
ES-AD ESNQ 8-13 IAC - ICAO RNP RWY 21 Download it from here >>
ES-AD ESNQ 9-1 VAC Download it from here >>
AIP ENR 1.1.14 - Mountainous area of Sweden- Download it from here >>
Airport Bus
Airport bus transfer is run by local municipality “Kiruna kommun” and operated by Hörvalls bus. The airport bus transfer is available all year around at arrival and departures to/from Kiruna Airport.
The bus departs in general 30 minutes after arrival and adjust at any delay. Please notice driver of any further delay such as private lost luggage service handling, to secure you do not miss the transfer, especially at late arrivals.
Airport coaches operate between the airport and central Kiruna via Hjalmar Lundbomsvägen and Malmvägen roads.
The timetable may and will change according to flight schedule during the year.
The airport bus connect only to regular flights to and from Stockholm Arlanda Airport.
Buy your ticket onboard the bus before departure.
Cash and most credit-card are accepted.
NOTE: No ATM for cash withdrawal at Kiruna Airport.
Information, price and timetables:
The route is operated by Hörvalls Buss
PH: +46 (0)980 - 81 311
Airport bus website, click here >>
Kiruna Airport Shuttle
Kiruna Airport Shuttle service will transfer you quickly and easily to and from Kiruna Airport direct to the door of selected hotels and within short walking distance of almost all accommodation in Kiruna.
Abisko Bus by Visit Abisko provides return Björkliden and Abisko bus transfer services from Kiruna airport, selected Kiruna hotels and ICEHOTEL direct to the Abisko and Björkliden area
Meeting most inbound and outbound flights our Kiruna Airport Transfer bus is a great way to start and finish your trip to Kiruna. Booking is easy and can be done directly with us online using our easy-to-use booking platform, ensuring you arrive confident that your seat is booked.
The route is operated by Abisko Bus
Book here >>
Bus to Narvik via Kiruna C, Abisko, Björkliden and Riksgränsen
Länstrafiken Norrbotten.
Bus line no 91 between Kiruna Airport via Kiruna Central Station to/from Narvik.
Timetable will not adjust in case of flight delays and/or change of flight schedules.
Timetable are available here >> (PDF) (Valid: 2020-06-12–2020-09-20)
Nikkaluoktaexpressen bus service
The bus stops at Kiruna Airport on the way to and from Nikkaluokta on each run.
This route is served between June 12 and September 20, 2020.
Read more on Frequently asked questions >>
For refund, cancel of tickets must be made at least 24 hours before departure.
Passengers have to prebook their ticket online before departure.
Timetables and prices are available online in Swedish and English here >>
Payment can be made by card or cash on board the bus, but tickets can also be purchased online here >>
The route is operated by Hörvalls Buss.
Flight and ski transfers
Tourist transfers
Visit Abisko offers a door to door airport shuttle to hotels in Kiruna, Abisko and Bjorkliden.
Book online at Visit Abisko website here >>
(For further info and booking - Click on link):
Information on airport homepage >>
Taxis are available right outside the terminals.
Flygtaxi
PH: +46 (0)8 - 120 920 00
Click here >> (opens in a new window)
Taxi Kiruna
PH: +46 (0)980 - 120 20
Click here >> (opens in a new window)
(For further info and booking - Click on link):
Information on airport homepage >>
SFSA Flight Support partners CarTrawler
At Kiruna Airport, you can rent cars at Hertz, Avis, Europcar,
Mabi, Sixt.
Note: Remember to book your rental car in advance
For drop-off of rental cars follow the signs from the airport entrance.
See the map here >>
(External link from Jönköping Airport - separate window will be open)
Car keys must be returned in the key drop available at the rental car agencies in the arrivals hall.
Globally, CarTrawler offers attractive rates for car hire in over 30,000 locations in more than 145 countries, and with over 1,200 international suppliers.
SFSA Flight Support Car Rental &Transfer services together with CarTrawler search over 1,600 car rental suppliers to find you the lowest price!
We have integrated the service digitally so that you can make your bookings through this website and our mobile airport website from anywhere.
INSTRUCTION (Choose option)
1. Aim your phone camera at the QR code to the left
2. Click on the button up to the right - with the text
"Click here for booking".
Swedavia AB
Kiruna Airport
Box 831
SE-981 28 Kiruna, Sweden
Terminal
Monday–Friday Ref AIP SUP/NOTAM
Saturday Ref AIP SUP/NOTAM
Sunday Ref AIP SUP/NOTAM
Air traffic
Monday-Friday H24
Saturday H24
Sunday H24
Ref AIP SUP/NOTAM
SFSA Flight Support/Svenskaflygplatser.com does not guarantee the accuracy or timeliness of any information on this site.
Use at your own risk.
NOT to be used as an official source for flight planning, navigation, or use in flight.
NOTE!
Notices, restrictions,and advisories may change at any time and without notice.
Do not attempt any operation whether in the National or in the International Airspace System without first obtaining and understanding a thorough pre-flight briefing.
