58 47 19N 016 54.13E
Stockholm Skavsta Flygplats AB
Box 44
SE-611 22 Nyköping
PH: +46 (0)155 - 28 04 21
FAX: +46 (0)155 - 28 04 83
Email: dispatch@skavsta.se, operations@skavsta.se
AFS: ESKNZTZX
OPERATIONS: NYOOPXH
Website: www.skavsta.se
"Stockholm Skavsta Airport (NYO) is located appx 106 kilometres SW of the city centre of Stockholm"
"Stockholm Skavsta Airport (NYO) is situated close to the E4 motorway outside Nyköping.
Use the exit 133 from the E4 and follow the signage “Skavsta” for 7 km"
https://www.visitstockholm.com/
"Stockholm Skavsta Airport (NYO) is situated close to the E4 motorway outside Nyköping
and is located appx 7 kilometres NW of the city centre of Nyköping"
https://nykopingsguiden.se/visit-nykoping/
ESKN/NYO
584719N 0165413E RWY 08/26 centre point
6° E 2020/+0.2 increasing
142 ft/43 m
Skavsta TWR
Phone:
+46 (0)155 - 28 04 20
Email address:
ats.skavsta@acr-sweden.se
CO ATS
Andreas Tinnerfelt
CO ATS Stockholm-Skavsta Airport
+46 (0)70 - 340 81 56
Email address:
andreas.tinnerfelt@acr-sweden.se
Postal address:
AVIATION CAPACITY RESOURCES AB, ACR
Östermalmsgatan 87E
SE-114 59 Stockholm, Sweden
ESKNZTZX
Skavsta TWR Primary (HO):
127.705 MHz
Skavsta TWR Emergency (HO):
121.500 MHz
Östgöta CTL:
132.950 MHz
CTR established during hours of TWR.
GND:
NIL
Skavsta ATIS:
126.280 CAT 1 MHz
ATIS service also available by ACARS for ACFT
equipped with ACARS-MU. (AEEC 623 compliant)
(Provider is: ARINC for datalink communication and ESOW
ATS for ATIS service.)
132.955 MHz ÖSTGÖTA APPROACH
DVOR/DME TRS
114.30 MHz
LLZ/DME RWY 08 WEK
111.30 MHz
ILS RWY 26 EKN CAT III
111.90 MHz
NDB:
398 (KHz) PEO (RWY 26)
364 (KHz) NW (RWY 08)
See AIP for more information
5000 ft AMSL
VFR Entry/Exit point
- LIDSJON 585333N 0165418E
- BOGSTA 585217N 0170823E
- MARSVIKEN 584149N 0165727E
- NORRTORP 584213N 0163742E
- VRENA 585155N 0164126E
Reporting point
- NIL
Holding
NORTH: Hold north of Täckhammar, north of
point 585013N 0165523E
SOUTH: Hold south of Bergshammar, south of
point 584413N 0165525E
NIL
RUNWAYS, LANDING AIDS, AD reference code
RWY 08
Dimension: Length 2 878 m Width 45 m
SURFACE: Asphalt PCN 60 F/B/X/T
THR ELEV: 114 ft
THR COORD: 584712.48N
0165257.22E
DECLARED DISTANCES
TORA: 2878 m
TODA: 2878 m
ASDA: 2878 m
LDA: 2750 m
LANDING AIDS:
APPROACH AND RUNWAY LIGHTNING
APCH LGT: SALS , 420 m
VASIS: PAPI
LED lights: RTHL, REDL, RENL, RCLL. No RCLL first 128 m
RWY 26
Dimension: Length 2 878 m Width 45 m
SURFACE: Asphalt PCN 60 F/B/X/T
THR ELEV: 127.8 ft
THR COORD: 584723.17N
0165547.18E
DECLARED DISTANCES
TORA: 2878 m
TODA: 3028 m
ASDA: 2878 m
LDA: 2878 m
LANDING AIDS:
APPROACH AND RUNWAY LIGHTNING
APCH LGT: Barrette CL
CAT II/III
900 m
VASIS: PAPI
LED lights: APCH, RTHL, REDL, RENL, RCLL, RTZL
RWY 16
Dimension: Length 2 581 m Width 45 m
SURFACE: Asphalt PCN 40 F/B/X/T
THR ELEV: 133 ft
THR COORD: 584804.95N
0165414.67E
DECLARED DISTANCES
TORA: 2043 m
TODA: 2043 m
ASDA: 2043 m
LDA: 2043 m
LANDING AIDS:
APPROACH AND RUNWAY LIGHTNING
APCH LGT: NIL
VASIS: PAPI
LED lights: EFAS, RWY Centre Line LGT and TDZ LGT
RWY 34
Dimension: Length 2 581 m Width 45 m
SURFACE: Asphalt PCN 40 F/B/X/T
THR ELEV: 131 ft
THR COORD: 584702.21N
0165454.40E
DECLARED DISTANCES
TORA: 2043 m
TODA: 2043 m
ASDA: 2043 m
LDA: 2043 m
LANDING AIDS:
APPROACH AND RUNWAY LIGHTNING
APCH LGT: NIL
VASIS: PAPI
LED lights:
TWY edge and centre line lighting Edge: TWY 2, 4, 5, A, B, C, F, G
At THR RWY 16/34, THR RWY 08/26 and at PAPI TWY B.
Lighted
windsock 265 m SW RWY intersection
AD reference code
RWY 08/26 code 4E, code F
capability available,
RWY 16/34 code 3C
APRON SURFACE AND STRENGTH
Apron 1 ASPH PCN 40 F/B/X/T 50% higher ACN accepted occasionally.
Apron 2 ASPH PCN 60 F/B/X/T 50% higher ACN accepted occasionally.
Apron 4 ASPH PCN 20 F/C/Y/T 50% higher ACN accepted occasionally.
Apron 5 ASPH PCN 20 F/C/X/T 50% higher ACN accepted occasionally.
TWY WIDTH, SURFACE AND STRENGTH
TWY A 24 m ASPH PCN 60/F/B/X/T
TWY B 23 m ASPH PCN 40/F/B/X/T
TWY C 44 m ASPH PCN 40/F/B/X/T
TWY E 15 m ASPH PCN 40/F/B/Y/U
TWY F 10 m ASPH PCN 20/F/B/Y/U
TWY G 8 m ASPH PCN 20/F/B/Y/U
TWY 2 18 m ASPH PCN 60/F/C/X/T
TWY 4 18 m ASPH PCN 20/F/C/Y/T 23 m PCN 60 F/C/X/T between TWY 2 and intersection TWY 5
TWY 5 15 m ASPH PCN 20/F/C/X/T
TWY 2 MAX aircraft ICAO CODE C
Remarks
TWY E MAX aircraft ICAO CODE B
TWY 2 MAX aircraft ICAO CODE C
TWY 4 MAX aircraft ICAO CODE C
STOCKHOLM/Skavsta AD may be used only:
MON: H24
TUE. H24
WED: H24
THU: H24
FRI: H24
SAT: H24
SUN: H24
ATS
H24
ATS ARO
H24
AD operator
H24 (reduced outside office hours)
AD Operating hours
H24
Fuel
H24
AVBL 1 HR PN 2100-0600 (2000-0500)
Handing
O/R
De-Icing
H24
AVBL 1 HR PN 2100-0600 (2000-0500)
Custom
H24
Immigration 0500-2100 (0400-2000)
Other hours O/R
IFR/VFR. Max RWY ref code 4C
Remarks:
AD reference code;
RWY 08/26 code 4E, code F capability available,
RWY 16/34 code 3C
PPR:
Prior Permission Required (PPR) for the following types of
flights within ÖSTGÖTA TMA;
• Aerial photographing
• Geological survey flights
• Parachute dropping
• Calibration flight for nav-aids and approach aids
Before submitting a flight plan the operator shall request prior
permission from ÖSTGÖTA TMC
PH: +46 (0)11 - 19 28 14
LOCAL AERODROME REGULATIONS
1. Restrictions för school and training flights
PPR required for all school and training flights. PPR also
required for all other flights involving TGL and/or airwork
within ESKN CTR.
Flights with touch-and-go landings are only permitted:
MON–FRI 0500–2000 (0400–1900)
SAT 0600–2000 (0500–1900)
SUN and HOL 0800–1500 (0700–1400)
When ÖSTGÖTA TMC is not in operation, training flights
within ÖSTGÖTA TMA may be carried out only after prior
permission from the Supervisor at STOCKHOLM ACC,
PH: +46 (0)8 - 585 547 02.
2. Apron 1 and Apron 2: Taxiing to stand position
When taxiing to stand position, guidance by manual
mashalling signals is mandatory. In addition to manual
marshalling signals, a “Follow-Me car” may be used.
3. Avoidance of jet blast
Use idle thrust due to jet blast risk when taxiing to stands 8, 9
and 10A.
GA (General Aviation) parking
Primarily on apron 5. Otherwise on apron 4.
Leave apron 4 and apron 5 via gate G50 on foot.
Escort from GA counter at Gate 50 inside terminal to apron.
Reduced RWY separation
Reduced RWY separation applies at the aerodrome according
to AD 1.1 para 10.
Granted exemptions from requirements in
CS-ADR-CSN:
• Obstacles penetrate the obstacle limitation surfaces.
• TWY 2 and 4 is partly missing paved shoulder.
• Taxiway curves in connection with runway
intersection, TWY B, C and 2, does not meet the
EASA requirement of taxiway curve radius.
THR RWY 08
permanently displaced 128 m
.
Helicopters
hover via marked taxiways only.
Caution
floodlight masts.
Apron 4:
Max wing span 36 m.
Parking coordination required (Skavsta Operations, freq. 130.180 MHz).
Marshalling available O/R (TWR).
RWY 16/34:
RGL crossbar (amber) north/south of RWY intersection are inset in the surface of RWY.
• Sharpened attention in connection with taxiing around the runway cross
Parachuting
occurs
Grass Field parallel to RWY 16/34
permanently closed
Traffic circuit
NO INFO
Outside of TWR HR of OPS
NO INFO
During TWR HR of OPS
NO INFO
Low visibility procedures (LVP) established
• LVP will be in force when RVR is below 550 m or ceiling or
vertical visibility is below 200 ft.
• LVP will be preceded by a runway inspection.
• The application of LVP will be announced by ATIS and/ or
ATC.
• When LVP is applied only one aircraft or vehicles are allowed
in the manoeuvring area.
• When LVP is applied aircraft shall report arriving at position
stand or in front of hangar.
Handling agent(s):
Stockholm Skavsta Airport AB
1.STOCKHOLM SKAVSTA AIRPORT:
Handling agent is the airport company.
Full handling – passenger and cargo – for all aircraft incl. B747.
Handling on request via e-mail or SITA.
Contact the airport office for car rentals and hotel reservations.
Taxis may be ordered by radio 15 minutes before ETA.
Contact
Email: operations@skavsta.se
SITA: NYOOPXH
Stockholm Skavsta Airport AB
Box 44
S-611 22 Nyköping , Sweden
VISITING ADDRESS
Stockholm Skavsta Airport AB
General Schybergs plan 22
611 92 Nyköping , Sweden
PH:
FBO Fax no:
Email: operations@skavsta.se
SITA: NYOOPXH
VHF:
WWW:
https://www.skavsta.se
Payments:
Carnet: UVair, Visa/Mastercard, American Express
NYO Dispatch
PH: +46 (0)155 - 28 04 21
Email: dispatch@skavsta.se
SITA: NYOOPXH
Custom H24
Immigration 0500-2100 (0400-2000) Other hours O/R
Jet A1 Air BP via YMFAS:
PH +46 (0)733 - 54 04 41
100 LL Air BP via YMFAS:
PH:+46 (0)733 - 54 04 41
YM Fueling Services AB, YMFAS/Air BP
PH: +46 (0)733 - 54 04 41
OIL:
-
Available, Type I and II
AD category for fire fighting:
1. AD category for fire fighting
CAT 7 for scheduled traffic, CAT 8 and 9 on request.
2. Rescue equipment
Rescue and fire fighting services vehicles, medical supplies,
decontamination material + municipal rescue service.
3. Capability for removal of disabled aircraft
Capability for removal of disabled aircraft Suitable for ACFT up to B747-8
Contact Field service
PH: +46 (0)70 - 328 18 16
E-mail: field@skavsta.se
4.
Remarks
Fire fighting and rescue available on request for non-contracted airlines
PPR for RFFS via Email to: nyorffs@skavsta.se
Charges and Conditions, see www.skavsta.se
1.
Aircraft certificated in accordance with ICAO Annex 16, Vol I,
Chapter 1 and 2 must not use the aerodrome.
2.
Noise Abetment Departure Procedure alleviating noise at
the aerodrome (NADP 2) shall be used.
Ref ICAO Procedures for AIR Navigation Services – Aircraft Operations
(PANS-OPS Doc 8168) Vol I – Flight Procedures.
3.
For aircraft with MTOM exceeding 7000 kg the following
applies:
a. Daily 0600-1700 (0500-1600). Aircraft performing visual
APCH must not descend below 2000 ft AMSL before
established on RWY CL.
b. Daily 1700-0600 (1600-0500): Visual approach not
permitted.
4. Over built up areas
Over Nyköping and Stigtomta aircraft should not be operated
below 3000 ft AMSL, except when necessary for take-off and
landing.
Routes for inbound and outbound traffic, IFR and VFR, have
been established also for noise abatement.
Aircraft shall strictly adhere to assigned route and be operated in such a
manner that unnecessary noise disturbances are not caused.
If no suitable aerodrome is within reach;
1. SQUAWK 7600
2. Enter CTR via VRENA/BOGSTA – Holding
NORTH or via MARSVIKEN/NORRTORP–
Holding SOUTH at or below 1500 ft AMSL.
Transmit blind your intentions.
3. Flash LDG-lights and watch TWR for optical
signals.
According to AIP
Security charges are set and invoiced by governmental Transportstyrelsen (Swedish Transport Agency) directly to airline operator. See www.transportstyrelsen.se (TSFS 2012:113)
Increased charges outside TWR HR of OPS
Stockholm Skavsta Airport AB - LANDING FEES AND CHARGES
Information about landing fees and conditions of use:
Charges and Conditions of Use 2019, Click here >> (New window with pdf-document)
Via HANDLING (See above)
NO/NIL
The airport have a shop immediately after the security check and is open at all departures.
You who travel domestically and within the EU can shop from their range of perfumes, skincare, sweets, souvenirs etc.
Carnets Jet A1:
Air BP only
Carnets 100LL,91/96 UL:
Prior arrangement required through handling companies.
Oil prior arrangement required.
Via HANDLING (See above)
Credit Cards accepted at the airport: Diners Club, Master Card, Eurocard, VISA, UVair and AMEX (American Express)
Airport Manager (Director) (VD):
Peter Steinmetz
Email: peter.steinmetz@skavsta.se
PH: +46 (0)155 - 280445
Airlines
Ryanair/WizzAir: Contact the airport information desk
Nyköpings FK (Flying Club)
PH: +46 (0)155 - 26 71 83
Nyköpings Fallskärmsklubb
PH: +46 (0)73 - 634 35 60
SAAB Aerotach, switch board
PH: +46 (0)155 - 771 00
See HANDLING above
The AIP links below are obtained externally from LFV AB (publisher of AIP).
AIP updates are based on the AIRAC effective date schedule.
But if the link does not work or is not updated, please log in to
aro.lfv.se: for current information:
ES-AD ESKN 1-1 Download it from here >>
ES-AD ESKN 2-1 Aerodrome Chart - ICAO Download it from here >>
ES-AD ESKN 2-3 AERODROME CHART/ MARKINGS Download it from here >>
ES-AD ESKN 5-1 Area Chart ESSP Area Chart - ICAO ÖSTGÖTA TMA (ESSP NORRKÖPING-KUNGSÄNGEN 5) Download it from here >>
ES-AD ESKN 6-1 IAC - RNAV SID General Download it from here >>
ES-AD ESKN 6-3 IAC - SID - ICAO RNAV (GNSS) SID RWY 08 Download it from here >>
ES-AD ESKN 6-5 IAC - SID - ICAO RNAV (GNSS) SID RWY 26 Download it from here >>
ES-AD ESKN 6-9 IAC - RNAV STAR General Download it from here >>
ES-AD ESKN 6-11 IAC - STAR - ICAO RNAV (GNSS) STAR RWY 08 Download it from here >>
ES-AD ESKN 6-13 IAC - STAR - ICAO RNAV (GNSS) STAR RWY 26 Download it from here >>
ES-AD ESKN 6-17 IAC - STAR - ICAO RWY 26 Download it from here >>
ES-AD ESKN 7-1 IAC - ICAO ATC Surveillance Minimum Altitude Chart – ÖSTGÖTA Download it from here >>
ES-AD ESKN 8-1 IAC - ICAO ILS or LOC RWY 26 Download it from here >>
ES-AD ESKN 8-2 IAC - ICAO NDB RWY 26 Download it from here >>
ES-AD ESKN 8-3 IAC - ICAO LOC RWY 08 Download it from here >>
ES-AD ESKN 8-4 IAC - ICAO NDB RWY 08 Download it from here >>
ES-AD ESKN 9-1 VAC Download it from here >>
You can choose between:
- Airport shuttle bus
Flygbussarna-Airport coaches >>
- Airport shuttle bus
FLIXBUS >>
- Local bus number 515 (pdf) will take you to/from Nyköping city center via the train- and bus stations, from where you can travel onwards.
Sörmlandstrafiken >>
(For further infolinks and booking - Click on links)
Information on airport homepage >>
The taxi ramp is located at the main entrance of the airport terminal.
(For further info and booking - Click on link):
Information on airport homepage >>
The local train station in Nyköping is 7 km away from the airport. Take a taxi or the local bus service no. 515 to/from the train station.
Buy your ticket at sj.se, in the ticket machine at the train station or in the SJ app.
Information on SJ homepage >>
PHONE: +46(0)155 - 28 80 20
BOOKING/CUSTOMER SERVICE (Norway):
+47 (22)-33 42 00
PHONE: +46(0)11 - 15 65 00
BOOKING/CUSTOMER SERVICE (Norway):
+47 (22)-33 42 00
PHONE: +46(0)8-676 98 00
BOOKING/CUSTOMER SERVICE (Norway):
+47 (22)-33 42 00
PHONE: +46(0)8-692 52 00
BOOKING/CUSTOMER SERVICE (Norway):
+47 (22)-33 42 00
SFSA Flight Support partners CarTrawler
At Stockholm Skavsta Airport, you can rent cars at Hertz, Avis, Budget, Sixt, Mabi och Europcar.
Collection of your rental car takes place in connection with arrival at a signposted service desk
Globally, CarTrawler offers attractive rates for car hire in over 30,000 locations in more than 145 countries, and with over 1,200 international suppliers.
SFSA Flight Support Car Rental &Transfer services together with CarTrawler search over 1,600 car rental suppliers to find you the lowest price!
We have integrated the service digitally so that you can make your bookings through this website and our mobile airport website from anywhere.
INSTRUCTION (Choose option)
1. Aim your phone camera at the QR code to the left
2. Click on the button up to the right - with the text
"Click here for booking".
Stockholm Skavsta Flygplats AB
Box 44
SE-611 22 Nyköping, Sweden
Terminal
Monday H24
Tuesday H24
Wednesday H24
Thursday H24
Friday H24
Saturday H24
Sunday H24
Air traffic
Monday-Friday H24
Saturday H24
Sunday H24
SFSA Flight Support/Svenskaflygplatser.com does not guarantee the accuracy or timeliness of any information on this site.
Use at your own risk.
NOT to be used as an official source for flight planning, navigation, or use in flight.
NOTE!
Notices, restrictions and advisories may change at any time and without notice.
Do not attempt any operation whether in the National or in the International Airspace System without first obtaining and understanding a thorough pre-flight briefing.
